直線導軌和直線滑軌是一樣的嗎?
來源:http://m.zhzdh888.com/ 日期:2023-02-04 發布人:
直線導軌和直線滑軌全是機械設備里邊的一個零配件,承擔一定的負載,在高負荷的狀況下完成該精密度的運轉運動。但直線導軌和直線滑軌以前并并不是一樣的,還是有存有不一樣的地方,今天導軌絲杠小編就來為大家做一個詳細的講解。
The linear guide rail and the linear slide rail are all parts inside the mechanical equipment, which bear a certain load and complete the precise operation movement under the condition of high load. But the linear guide rail and the linear guide rail were not the same before, and there are still differences. Today, the guide rail lead screw editor will give you a detailed explanation.


直線導軌和直線滑軌都是一種直線滑動裝置,直線導軌是很多種導軌的一種統稱,直線導軌又可稱之為線軌,線性滑軌、雙軸心導軌。直線滑軌是直線導軌的一種。直線導軌可以分為滑動導軌和滾動導軌。滑動導軌是導軌和滑塊直接接觸,較低,精度也低,摩擦系數大。滾動導軌是在導軌和滑塊之間裝有滾動體(滾柱或滾珠),滾動導軌,結構較復雜,也比較高點,摩擦系數小,精度高。所有直線行駛作為導向滑動軌道,都可以統稱為直線導軌,像雙軸心導軌、線性滑軌、滾動導軌這些都是直線導軌的種類。
Both linear guideway and linear guideway are linear sliding devices. Linear guideway is a general name of many kinds of guideways. Linear guideway can also be called linear guideway, linear guideway and double-axis guideway. Linear guideway is a kind of linear guideway. Linear guide rail can be divided into sliding guide rail and rolling guide rail. The sliding guide rail is the direct contact between the guide rail and the sliding block, with low price, low precision and large friction coefficient. The rolling guide rail is equipped with a rolling body (roller or ball) between the guide rail and the slider. The rolling guide rail has a complex structure, high price, low friction coefficient and high accuracy. All straight-line running as guided sliding rails can be collectively referred to as linear guide rails, such as double-axis guide rails, linear guide rails and rolling guide rails.
像CSK直線導軌就是里面的其中一種類型,它的作用主要用來支撐和引導運動部件,讓它按照指定的方向做復線運動。由鋼珠在滑塊與導軌之間做無限的循環滾動,讓一些負載的平臺可以沿著導軌以高精度做線性運動,大大降低了摩擦系數,是比普通傳統的的滑動導軌1/50。如此一來,便可以輕易的達到um級的定位精度。
Like CSK linear guide rail, it is one of the types. Its function is mainly to support and guide moving parts to make them move in the specified direction. The steel ball makes infinite circular rolling between the sliding block and the guide rail, so that some loaded platforms can move linearly along the guide rail with high accuracy, greatly reducing the friction coefficient, which is 1/50 of the ordinary traditional sliding guide rail. In this way, the positioning accuracy of um level can be easily achieved.
以上就是直線導軌和直線滑軌的詳細介紹,希望會對您有所幫助。如果您還想要了解更多相關資訊,歡迎繼續關注我們的http://m.zhzdh888.com網站。
The above is the detailed introduction of linear guide rail and linear slide rail. I hope it will help you. If you want to learn more about this, please continue to follow our http://m.zhzdh888.com Website.
